1. Introduction¶

The CORE-1126BJD4 development board utilizes the Rockchip quad-core AI vision processor RV1126B, integrating a 3-tops NPU to support lightweight AI large models and deep learning frameworks. It features a built-in 12M ISP, an 8MP AI-ISP, and integrated accelerators for various algorithms. It supports 12M video encoding, 4K video decoding, and simultaneous input from up to three cameras. It uses a 260P gold-finger interface and is compact in size. It is widely applicable in industries such as face recognition, turnstile access control, smart security, and smart network cameras.

CORE-1126BJD4 can be combined with different base plates to form different product shapes. It can be used to form the AIO-1126BJD4 kit and the AIO-1126BJD4V0 kit.

CORE-1126BJD4 front：

_images/CORE-1126BJD4-front.png

CORE-1126BJD4 back：

_images/CORE-1126BJD4-back.png

1.1. AIO-1126BJD4¶

The AIO-1126BJD4 development board consists of the core board CORE-1126BJD4 and a new baseboard MB-JD4-RV1126B. This wiki describes the use of this board.

AIO-1126BJD4 front：

_images/AIO-1126BJD4-front.png
